| Message: | 6in 6out Max Capacity 1440cores Fiber Optic Splice Closure (GJM467) Basic Info Model NO.:GJSW-467 Working Life:25 Years Specification:ISO 9001,Website:http://www.hzzrfttx.com, TLC Cable Diameter:7mm~25mm Weight::5.0kg Cable port:6in 6out Dimension:278mm(Diameter)×560mm Sealing Method:Mechanical Seal and Sticky Cincture Seal Max Capacity:1440 Cores Product Description 1. The Fiber Optic Splice Closure (FOSC) is widely used for connecting of optic cables. It can be installed aerial, buried/underground and wall mounting for network of direct fiber connection or branch fiber connection.
2. The case of Fiber Optic Splice Closure (FOSC) is made of high quality Polycarbonate (PC) to make sure good performance of anti-aging and anti-erosion against acid and alkali salt. The reliable mechanical structure of the FOSC case provides good performance of resisting wild environment, intensive climate changes and serious working environment, meanwhile it gives excellent waterproof and dustproof.
3. The metal fittings of the Fiber Optic Splice Closure (FOSC) are made from high-quality stainless steel to resist erosion perfectly.
4. Easy to open, and it can be opened and used repeatedly.Technical DataEnvironment Temperature:-40ºC~+65ºCAtmospheric pressure:70~106kPaSealing Performance: Inflation pressure100kPa/24hTension:800N/1minWafering: 2000N/100mmImpact: 1m/1kg Steel ball / three timesBending: 150N/±45°/10 cyclesTorsion: 50N.m/+90°/10 cyclesInsulated Resistance: 2X104MΩ/500VCompression strength: 15kV/1min/10mA |
