| Message: | 1.Detailed Description
1. Inner Conductor: CU, CCA, CCS
2. Dielectric: Foam/Solid PE
3. Shield: Bonded, Non-bonded, Single, Double
4. Braid wire material: CU, AL-Mg, TC
5. Braid wire diameter: 0.12mm, 0.15mm, 0.16mm
6. Braid net: 48, 64, 72, 80, 96, 128 and more
7. Braid coverage: 40%, 50%, 60%, 80%, 90% and more
8. Jacket: PE/PVC
9. Jacket degree: 60, 65, 68, 70,75
10. Customized requirement welcomed.
2.Construction
Conductor
Material
Bare Copper
Nom. Dia.
14AWG(7*0.75mm)
Dielectric
Material
Foam PE
Nom. Dia.
7.24± 0.02mm
Shield
Material
Al foil+ Al braiding)*2
Coverage
85%
Jacket
Material
PVC/PE
Nom. Dia.
10.30± 0.10mm
Nom. Thick
0.86mm
3.Electrical Specifications
Characteristic Impedance(Ohm)
75
Nominal Velocity of Propagation (%)
85
Nominal Capacitance(pF/m)
50
Sparker Test(VAC)
4000
SRL(dB, min)
20
4.Attenuation
Attenuation Performance[68°F(20°C)]
Frequency(MHZ)
Maximum(Db/100ft)
Maximum(dB/100m)
5
0.38
1.25
55
0.96
3.15
250
2.05
6.72
300
2.25
7.38
450
2.75
9.02
600
3.18
10.43
750
3.65
11.97
865
3.98
13.05
1000
4.35
14.27
1450
5.42
17.78
1750
6.10
20.01
5.Application
The RG 213 coax cable is a low-loss coated cable that is noncontaminating. Coax Cables transmit radio signals, video signals, measurement signals and data signals and are often used in home entertainment systems. The RG 213 is generally considered the superior coax cable because it is low-loss and consists of seven braided strands of bare copper.
(1) CATV-community antenna television.
(2) CCTV-closed-circuit television.
(3) DBS-direct broadcasting satellite. url:http://www.chinahuiercable.com |
