| Message: | Techniques
1, Industrial-grade enclosed machine structure with imported main accessories,can adapt to the industrial-ore environment with high dust,high pollution,high corrosion,so that application is wider with longer life.
2,Adopt 32bit true color image processing method,and applied the mathematical morphology based on HIS color space,so as to achieve better separation effect,to improve the ability to color machine flexibility and sorting operation.
3,High precision full-color plane array CCD sensor technology,can detect the subtle color difference in 0.02mmsq according to the different characteristics of the ore,by using the unique image processing method ,to ensure the accuracy of the sorting materials such as ore identification.
4,Software adoptsunique algorithrm,a fast calculation speed,high output,part of the aircraft producction has exceeded 40 tons/hour ,4 to 5 time that of similar domestic manufacturers,which can fully match the mine manufacturers with the requirements on high capacity and high accuracy.
型号/Model MS-KS-4 整机功率/ Power (kW) 8
产量/
Capacity（T/H）
25~45（6cM≤d≤10cM） 气源压力/Air Pressure (Mpa)
0.6（6cM≤d≤10cM）
15~25（3cM≤d≤6cM） 0.5（3cM≤d≤6cM）
10~15（1cM≤d≤3cM） 0.4（1cM≤d≤3cM）
3~10（d≤1cM） 0.3（d≤1cM）
色选精度/Sorting accuracy （%） ≥99.9 气源消耗/Consumption(L/min) ≤5000
最优带出比/Optimized carryover ≥50:1 整机重量/Weight(Kg) 3000
电源/ Power Supply AC220V 50HZ 外形尺寸/Dimension (L×W×H:mm) 4850×2650×2750
Note：1、d means the dimension(mm) of the sorting machine
2,the above data is worked out base on cobblestone with 5% impurity,it may vary according to different materials and different impurities percentage ,etc.
|
